EQUINOX 700 Features:

The Multi-IQ Advantage
Why Minelab Multi-IQ? Because with Minelab’s revolutionary Multi-IQ technology, you’ve got the combined power of multiple detectors in one — all working for you at the same time. Nothing goes undiscovered and no terrain is off limits. Silver, relics or jewellery. Park, field, or beach. Unearth the power of EQUINOX powered by Multi-IQ.

WATERPROOF
With IP68 waterproof capability to 5 m (16 ft), take EQUINOX anywhere and own the ground beneath your feet.

TARGET SEPARATION
Recovery Speed and Iron Bias controls how your detector responds to multiple signals: from minimising your chances of digging iron to sniffing out gold and treasures hiding within the trashiest ground and everything in between.

LIGHT AND COMPACT
Comprising lightweight 3-piece carbon-fibre shafts, EQUINOX 700 weighs only 1.2 kg (2.8 lb) and packs down to a mere 61 cm (24 in) — throw it in your backpack, and you’re all set.

ADVANCED AUDIO CONTROL
With multiple tone audio options, the sound of treasure has never been clearer — EQUINOX’s superior audio means you’ll not only ‘hear’ if a target is trash or treasure but you’ll also be able to gauge its size and depth simply by listening.

EXTREME PRECISION
The EQUINOX Multi-IQ engine delivers Stable IDs for even the deepest targets. Depend on solid, stable information to tell you whether to dig in or move on — when you’ve got a target, switch to Pinpoint Mode to zero-in further.

4 SINGLE FREQUENCY OPTIONS
For those with a specific goal in mind, EQUINOX® delivers total control and the power to choose from four single frequencies: 4/5/10/15 kHz.

LIGHTING AND VIBRATION
The daylight may have ended, but that doesn’t mean your hunt has to — with Control Pod Flashlight, Red Backlight Display, Backlit Keypad, and Handgrip Vibration you can power on long after the sun has gone.

LOUD AND CLEAR AUDIO
Enjoy the crystal-clear audio with lightning-fast Low Latency Wireless Headphones and In-Built Speaker (Included), or Wired Headphones and Waterproof Headphones (Accessories).

EQUINOX 700 Specification

Search Modes
Park, Field, Beach
All-Metal Shortcut
Yes
Custom Search Profiles
6
User Profile Button
No
Operating Frequencies (kHz)
Multi, 4, 5, 10, 15
Noise Cancel
Auto (19 Channels)
Ground Balance
Auto, Manual, Tracking
Sensitivity
1 to 25
Target Volume
0 to 25
Threshold Level
0 to 25
Threshold Pitch
Fixed
Target Identification (TID)
119 segment notch discrimination: Ferrous: -19 to 0 I Non-ferrous: 1 to 99
Target Tones
1,2, 5, All Tones (At), Depth (dP)
Tone Break
Ferrous (T1)
Tone Pitch
Tone 1 adjustable: 0 to 25
Tone Volume
Tone 1 adjustable: 0 to 25
Recovery Speed
1 to 3
Iron Bis
0 to 3
Depth Indicator
5 Levels
Discrimination Segments
119 Segments
Pinpoint Mode
Yes
Wireless Audio
Yes
Length (approx.)
Collapsed: 61 cm (24 in) - Extended: 144 cm (56.7 in)
Weight
1.27 kg (2.8 lbs)
Display
Monochrome LCD
Display and Keypad Backlight (red)
Off, High, Low
Flashlight
On, Off
Vibration
On, Off with separate Ferrous Control
Supplied Coil
EQX11 11" Double-D coil with skid plate
Audio Output
In-built loudspeaker, Wired 3.5 mm (1/8") headphones, Wireless headphones
Supplied Headphones
Minelab ML 85 Low Latency wireless headphones
Battery
3.7V/5100 mAh Internal Lithium-lon battery
Additional Included Accessories
Getting Started Guide, Screen Protector (English), Charging Cable
Waterproof
5m (16 ft) IP68
Operating Temperature Range
-10 to +40 degrees celcius (+14 to +104 degrees fahrenheit)
Storage Temperature Range
-20 to +70 degrees celcius (-40 to +158 degrees fahrenheit)
Key Technologies
Multi-IQ

EQUINOX 900 Features:

The Multi-IQ Advantage
Why Minelab Multi-IQ? Because with Minelab’s revolutionary Multi-IQ technology, you’ve got the combined power of multiple detectors in one — all working for you at the same time. Nothing goes undiscovered and no terrain is off limits. Silver, relics or jewellery. Park, field, or beach. Unearth the power of EQUINOX powered by Multi-IQ.

WATERPROOF
With IP68 waterproof capability to 5 m (16 ft), take EQUINOX anywhere and own the ground beneath your feet.

TARGET SEPARATION
Recovery Speed and Iron Bias controls how your detector responds to multiple signals: from minimising your chances of digging iron to sniffing out gold and treasures hiding within the trashiest ground and everything in between.

LIGHT AND COMPACT
Comprising lightweight 3-piece carbon-fibre shafts, EQUINOX 700 weighs only 1.2 kg (2.8 lb) and packs down to a mere 61 cm (24 in) — throw it in your backpack, and you’re all set.

ADVANCED AUDIO CONTROL
With multiple tone audio options, the sound of treasure has never been clearer — EQUINOX’s superior audio means you’ll not only ‘hear’ if a target is trash or treasure but you’ll also be able to gauge its size and depth simply by listening.

EXTREME PRECISION
The EQUINOX Multi-IQ engine delivers Stable IDs for even the deepest targets. Depend on solid, stable information to tell you whether to dig in or move on — when you’ve got a target, switch to Pinpoint Mode to zero-in further.

6 SINGLE FREQUENCY OPTIONS
For those with a specific goal in mind, EQUINOX® delivers total control and the power to choose from six single frequencies: 4/5/10/15/20/40 kHz.

LIGHTING AND VIBRATION
The daylight may have ended, but that doesn’t mean your hunt has to — with Control Pod Flashlight, Red Backlight Display, Backlit Keypad, and Handgrip Vibration you can power on long after the sun has gone.

LOUD AND CLEAR AUDIO
Enjoy the crystal-clear audio with lightning-fast Low Latency Wireless Headphones and In-Built Speaker (Included), or Wired Headphones and Waterproof Headphones (Accessories).

EQUINOX 900 Specification

Search Modes
Park, Field, Beach, Gold
All-Metal Shortcut
Yes
Custom Search Profiles
8
User Profile Button
Yes
Operating Frequencies (kHz)
Multi, 4, 5, 10, 15, 20, 40
Noise Cancel
Auto (19 Channels), Manual
Ground Balance
Auto, Manual, Tracking
Sensitivity
1 to 28
Target Volume
0 to 25
Threshold Level
0 to 25
Threshold Pitch
0 to 25
Target Identification (TID)
119 segment notch discrimination: Ferrous: -19 to 0 I Non-ferrous: 1 to 99
Target Tones
1,2, 5, All Tones (At), Depth (dP)
Tone Break
Ferrous, Non-ferrous (t1, t2, t3, t4)
Tone Pitch
All tones adjustable: 0 to 25
Tone Volume
All tones adjustable: 0 to 25
Recovery Speed
1 to 8
Iron Bias
0 to 9
Depth Indicator
5 levels
Discrimination Segments
119 segments
Pinpoint Mode
Yes
Wireless Audio
Yes
Length (approx.)
Collapsed: 61 cm (24 in) - Extended: 144 cm (56.7 in)
Weight
1.27 kg (2.8 lbs)
Display
Monochrome LCD
Display and Keypad Backlight (red)
Off, High, Medium, Low
Flashlight
On, Off
Vibration
On, Off per Tone Region
Supplied Coil
EQX11 11" Double-D coil with skid plate, EQX06 6" Coil with skid plate
Audio Output
In-built loudspeaker, Wired 3.5 mm (1/8") headphones, Wireless headphones
Supplied Headphones
Minelab ML 85 Low Latency wireless headphones
Battery
3.7V/5100 mAh Internal Lithium-lon battery
Additional Included Accessories
Getting Started Guide, Screen Protector (English), Charging Cable
Waterproof
5m (16 ft) IP68
Operating Temperature Range
-10 to +40 degrees celcius (+14 to +104 degrees fahrenheit)
Storage Temperature Range
-20 to +70 degrees celcius (-40 to +158 degrees fahrenheit)
Key Technologies
Multi-IQ
